Production accounting · Allocation · Visualization
Allocated volumes you can defend.
Pro-Hub turns measured volumes into auditable, well-level gross and net production through configurable, date-effective allocation networks. Built for production accountants and engineers.
- Networks
- Date-effective
- Results
- Gross & net
- Deploy
- Cloud / on-prem
| Well | Theo. bbl | Factor | Alloc. bbl |
|---|---|---|---|
| W-101 | 420.0 | 0.9538 | 400.6 |
| W-102 | 310.0 | 0.9538 | 295.7 |
| W-103 | 380.0 | 0.9538 | 362.5 |
| W-104 | 190.0 | 0.9538 | 181.2 |
| M-OIL | 1,300.0 | Σ | 1,240.0 |
Illustrative example: oil prorated to theoretical production.
What Pro-Hub does
Hydrocarbon production accounting, allocation and visualization.
Pro-Hub takes measured volumes from meters, tanks, theoretical and well tests, SCADA and samples. It applies configurable allocation networks and rules, then produces allocated volumes at the well and completion level, gross and net. Those volumes drive revenue, royalties, partner accounting, regulatory reporting and operational analysis, across simple-to-complex, multi-tier relationships among wells, tanks, meters and other equipment.
- 01 · Measure
Measured volumes in
Meters, tanks, theoretical and well tests, SCADA and laboratory samples.
- 02 · Allocate
Configurable networks and rules
Multi-tier, date-effective allocation networks with proration, well-test, meter-based and component methods.
- 03 · Account
Allocated volumes out
Gross and net volumes at well and completion level for revenue, royalties, partners, regulators and operations.
Platform
Six capabilities. One allocation record.
From the schematic you draw to the net volume your revenue team books, every step runs on the same audited dataset.
Allocation engine & network modeling
Build allocation systems graphically and let rules change over time without rewriting history.
- Graphical schematic builder
- Multi-tier hierarchies
- Date-effective configuration
Product & volume handling
Oil, gas, water, condensate, NGL components and residue gas in one consistent model.
- Full product coverage
- Component-level NGLs
- Dual and multi-product allocation
Dispositions, tracking & accounting outputs
Every molecule has a destination. Allocated results feed revenue, royalty and JV accounting.
- Full disposition tracking
- Gross and net volumes
- NGL accounting and BOE
Data integration & inputs
Meters, tanks, SCADA, well tests and lab samples in. Validated volumes out.
- Measured volumes
- Theoretical calculation meters
- Sample-driven component splits
Configuration, usability & governance
Configurable to your operation. Controlled and auditable at every step.
- Highly configurable
- User-defined groupings
- Role-based security
Visualization, reporting & agentic AI
See the network, report the numbers, and put an AI agent to work on the exceptions.
- Network visualization
- Reporting
- Agentic AI
W-103 · Battery A
362.5 bbl
Illustrative · allocated oil, prorated
From the field to the ledger
One set of numbers, from the wellhead to the revenue ledger.
A barrel is measured in the field, reconciled at the battery, allocated to a completion and booked by finance. When each step lives in a different spreadsheet, nobody quite agrees on the number.
Pro-Hub keeps every step on the same record, so the volume measured in the field is the volume the revenue team books.
- Field and production engineers
- Model the network as it physically exists and validate measurements at the source.
- Production accountants
- Reconcile daily, allocate monthly, and restate prior periods with a full audit trail.
- Revenue, royalty and JV teams
- Receive gross and net volumes they can pay against.
Engineering principles
Built around how fields actually flow.
Allocation errors rarely come from arithmetic. They come from a model that does not match the physical system, or one that quietly rewrites the past. Pro-Hub is designed against both.
History is immutable by default
Networks and rules are date-effective. A tie-in or meter change applies from its effective date, and prior months stay exactly as reported.
One base unit, no compounding error
Volumes are stored once in a base unit and converted only for display, so conversion error never accumulates across tiers.
Equipment location matters
Fuel, flare, vent, lease use and gas lift are placed where they physically sit in the network, because location changes the allocated result.
Reconcile daily, not just at close
Daily and monthly reconciliation surfaces imbalances while they can still be investigated, which removes month-end surprises.
Try it
Move the meter. Watch every well respond.
This is proration, one of the allocation methods Pro-Hub runs. Change the volume measured at the sales meter, or shut a well in, and the volume is re-allocated in proportion to each well's theoretical production.
1,240.0 bbl
Battery A wells
W-101
Theoretical 420.0 bbl
W-102
Theoretical 310.0 bbl
W-103
Theoretical 380.0 bbl
W-104
Theoretical 190.0 bbl
W-101
400.6
32.3%
W-102
295.7
23.8%
W-103
362.5
29.2%
W-104
181.2
14.6%
1,240.0 ÷ 1,300.0 theoretical = 0.9538
Σ 1,240.0 = M-OIL
Illustrative battery. Pro-Hub also allocates by well tests, meters and component analysis, across multi-tier networks.
Products & dispositions
Every stream, every destination.
Dual and multi-product allocation reconciles raw gas at the wellhead with processed NGL components on the plant statement, so allocated results tie to both measurement and settlement.
Products & components
- Oil
- Gas
- Water
- Condensate
- Residue gas
- Ethane
- Propane
- Iso-butane
- Normal butane
- Natural gasoline
- LPG
- Load oil
- Inhibitor
Dispositions tracked
- Sales
- Fuel
- Flare
- Vent
- Lease use
- Gas lift
- Transfers
- Inventory change
Outputs include gross and net volumes (WI/NRI), component-level NGL accounting, BOE, gain/loss and imbalance tracking, ready for revenue, royalty, partner balancing and JV accounting.
Governance
Configured to your operation. Controlled at every step.
Configurable
Custom screens, fields, labels, navigators and workflows.
Your hierarchies
User-defined groupings that match how your organisation reports.
Role-based security
Restrict access to specific areas of the database.
Audit trails
Who changed what, and when, recorded for every change.
Scales
From small operators to tens of thousands of properties and wells.
Cloud or on-premise
Deploy where your data governance requires it.
Go-live checklist
- Network mapped
- Sources connected
- Results validated
Implementation & support
We set it up with you, not just for you.
Allocation software is only as good as the network inside it. UES engineers work with your team to map wells, meters, tanks and facilities into Pro-Hub, then check the results against the numbers you already trust before you go live.
- Network modelling
- Your allocation systems mapped with your engineers, node by node.
- Data connections
- Meters, tanks, well tests, SCADA and lab samples brought in and validated.
- Training
- Hands-on sessions for field and office users.
- Ongoing support
- Help refining allocation methods as your assets change.
FAQ
Questions engineers ask first.
What is Pro-Hub?
Pro-Hub by UES is hydrocarbon production accounting, allocation and visualization software. It converts measured volumes from meters, tanks, well tests, SCADA and samples into allocated gross and net volumes at well and completion level.
What is hydrocarbon production allocation?
Production allocation is the process of distributing volumes measured at a shared point, such as a tank battery, facility or sales meter, back to the individual wells and completions that produced them, using rules such as proration, well tests, theoreticals or meter readings.
Who uses production allocation software?
Production accountants, production engineers, revenue and royalty teams, joint-venture accountants and regulatory reporting teams at oil and gas operators use allocation software to produce defensible, auditable volumes.
What allocation methods does Pro-Hub support?
Pro-Hub supports proration, theoretical production, well-test-based, meter-based and component-level allocation, configurable at each node of a multi-tier network.
Can allocation networks change without affecting historical results?
Yes. Pro-Hub networks and rules are date-effective. A change applies from its effective date forward, and prior periods keep their original configuration unless a prior-period adjustment is deliberately made, which is fully audited.
Which products and streams does Pro-Hub handle?
Oil, gas, water, condensate, residue gas and NGLs at component level (ethane, propane, iso- and normal butane, natural gasoline), along with LPG, inhibitor and load oil, and dispositions such as fuel, flare, vent, lease use and gas lift.
UES Energy Solutions Limited
Lagos, Nigeria · Oil & gas value chain
Built by UES
Built by an energy services company, not just a software vendor.
UES Energy Solutions works across the oil and gas value chain, from reservoir and subsurface studies to field services, engineering and production operations.
Pro-Hub is shaped by that work: by people who know what a test separator, a tank battery and a month-end close actually look like.
- Reservoir & subsurface studies
- Characterization, simulation and production forecasting.
- Oil & gas field services
- Well testing, production logging and surveillance.
- Engineering & operations
- Production optimization, integrity and HSE.
- Digital & technology
- Data acquisition, analytics and digital twins.
Next step
Put your allocation network in front of our engineers.
Walk us through your wells, facilities and month-end process. We will show you how Pro-Hub models it.
